Blast Equipment

SSCE 201-250

SSCE 201-250

201 series inner pipe blast machine working with sand blasting to clean the inner wall of cylinder. It can manual operation and automatic operation connecting with other equipment. This Series machine is wildly used in oil ,chemical, shipping industry for the pipe inner surface treatment before plating processing. The surface standard can reach to Sa2.5-Sa3. they are all easy to use safe with simply maintenance.




Model

SSCE201-250

Pipe Dia.

Φ60mm~Φ250mm

Air Consumption

3.1m3/min

Working Pressure

0.5-0.7MPa

Max.Abrasive Granularity

0.8mm

Surface Standard

Sa2-Sa3

 Dimension

Φ140×350

 Weight

 4kg



        The SSCE internal pipe blast machine is a special device of pneumatic sand blasting machine. It is a tool designed for cleaning internal pipelines. It is designed to blast clean without the necessity of rotating the pipe,easy to use and maintain. It can remove rust, old paint and any other contaminant much more efficiently than any other machines.

Working PrincipleWith the compressed air,  air flows send pressure and sand to the device. and then diverted two 130 ° angle blasting to to the pipe wall. Meanwhile, with the air counterforce, the nozzle head driven nozzles rotating, moving alongthe pipeline to clean .



SSCE 201-250结构图.png
